How to Optimize Your Mold Investment

Mold flow analysis is a powerful simulation tool that predicts how molten plastic will flow through a mold cavity during injection molding. With the ability to visualize flow patterns, pressure points, weld lines, and cooling behavior before physical tooling is made, engineers can proactively optimize product design, improve manufacturability, and significantly cut down development costs.

Let’s take a deep dive into why every engineer involved in part design or mold development should be leveraging mold flow analysis and how doing so can unlock measurable performance and cost advantage.

Understanding the High Upfront Investment

Injection molding is prized for its ability to produce consistent, high-quality parts at scale. It’s particularly cost-effective for mass production—running the same part in the thousands or even millions. But this efficiency comes at a price: the initial capital costs for molds can be steep, with some complex molds exceeding $70,000. This includes not only the design and tooling but also the rigorous testing required to ensure the mold performs reliably over time.

---

Key Factors Driving Mold Cost

1. Part Complexity and Tolerances

Before cutting steel, mold flow analysis gives you a virtual proving ground for your designs. It answers the critical “what-if” questions without incurring the cost of physical prototypes or tools.The intricacy of a molded component heavily influences mold design. Parts with tight tolerances, undercuts, or detailed surface finishes require more sophisticated—and therefore more expensive—molds. For critical applications, like pharmaceutical-grade products, tolerances of less than .001” are common, pushing costs higher. Additionally, choosing between single- and multi-cavity molds can affect both the cost and speed of production.

---

2. Mold Material

Mold longevity and performance are directly related to the materials used. Aluminum molds are a lower-cost option ideal for short runs, while steel molds, especially hardened varieties, are more durable and cost-effective over the long term. When molding abrasive materials like fiberglass or specialty resins such as fluoropolymers (FEP and PFA), selecting high-performance tooling materials becomes essential to withstand high temperatures, pressure, and corrosive outgassing.

---

3. Mold Manufacturing Location

Geographic location plays a role in both cost and lead time. While offshore mold builders (e.g., in Asia) can reduce initial costs, they may extend lead times by up to 25% and complicate quality control. Pexco leverages both global and in-house mold builders to balance cost, quality, and delivery, ensuring clients receive molds that align with their needs and budgets.

---

Working with Fluoropolymers

Hidden Costs and Performance Benefits

Fluoropolymers, including PFA (perfluoroalkoxy polymer) and FEP (fluorinated ethylene-propylene), are increasingly used in healthcare and high-performance applications due to their superior thermal, chemical, and electrical properties. However, their use in injection molding presents unique challenges.

Because of their shear sensitivity and high melt temperatures, PFA and FEP require specialized tooling and processing techniques. Performance Plastics has pioneered solutions such as:

These innovations allow clients to realize 20–40% savings in resin costs, a crucial advantage given the high price of these materials.
