Vivid Vinyl®
HS-2000
There is no equivalent weather resistant, large diameter heat shrink tubing in bright colors or crystal clear, for protecting large cables, poles and posts, rollers, tools, handles, and irregularly shaped objects for innovative outdoor and indoor applications.
Request More Information
"*" indicates required fields
Crystal Clear HS-2000 provides a transparent, conforming, protective fit, even over irregular shapes, allowing for visual inspection of instructions, warnings, etc.
Pexco’s weather-resistant, large diameter, colorful Vivid Vinyl® heat shrink tubing, in brilliant, eye-catching colors, is made from high-performance, flame-retardant polyvinylchloride enhanced with the strongest UV-resistant polymers.
Features and Benefits
- 2:1 shrink ratio
- Standard products come on spools
- Wide range of diameter sizes: 5/8-inches up to 5-inches with 2:1 shrink ratio
- Wide range of brilliant colors: High gloss colors, high visibility safety colors, metallic, translucent and matte finishes
- Heavy-duty, up to 50 mils thickness: Provides long–term protection for outdoor and indoor applications, guarding against abrasion, scratches, splinters, nicks and dings, rust, discoloration from harsh chemicals and fading from long-term UV exposure.
- Flame Retardant: Made from UL 94 compliant materials, environmentally friendly and safe, contains no hazardous materials, lead-free and RoHS compliant.
- High performance, flame retardant Polyvinylchloride
- The most attractive colors: There is no equivalent cosmetic heat shrink tubing
- Enhanced with the strongest UV resistant polymers for long-lasting, outdoor applications. Will not fade, crack, splinter or peel.
- List ItemUp to 50 mils thickness for tough abrasion resistance and long-lasting durability. Guards against abrasion, nicks and dings.
- Excellent resistance to harsh chemicals, oils, grease, acids, chlorinated cleansers, salt water, moisture, fungus. Will not stain, rust or mildew.
- Can be printed with text and graphics using durable inks
- Easy to clean: Provides years of maintenance-free protection
- Sizes range from 5/8″ up to 5-inches, for wide diameter applications
- Environmentally friendly and safe: Contains no hazardous materials
- ISO-9001:2015 certified and RoHS, REACH and Conflict Minerals compliant
- Made in the USA
* Including chlorinated cleaners, lubricating grease, penetrating oils, electrical insulation oils, and others.
Technical Specifications
- Shrink Ratio: 2:1
- Minimum
- Recommended Shrink Temperature: 100°C (212° F)
- Operating Temperature Range: -20°C to 105°C (-4°F to 221°F)
- Specific Gravity: 1.32
- Brittleness Temperature: -28°C
- Storage: Heat sensitive – Store at 70°F or belowVivid Vinyl HS-2000 comes in standard diameter sizes from 5/8″ up to 5″
Colors
- Not all colors and sizes are stocked – check the factory for availability and minimums
- We can custom match colors, finishes and PMS colors as well as print on Vivid Vinyl with durable inks (minimums may apply)
- Most colors are available in high gloss and translucent finishes
| Expanded I.D. Minimum |
Recovered I.D. Maximum |
Recovered Wall Nominal |
Standard Packaging (per box) Product on Spools |
||||||
|---|---|---|---|---|---|---|---|---|---|
| Size | in. | mm | in. | mm | in. | mm | ft. / Spool |
Total ft. / Box |
|
| 3/64 | .046 | 1.17 | .023 | 0.58 | .020 | 0.51 | * 1,000′ | 2,000′ | |
| 1/16 | .063 | 1.60 | .032 | 0.82 | .020 | 0.51 | * 1,000′ | 2,000′ | |
| 3/32 | .093 | 2.36 | .046 | 1.17 | .025 | 0.64 | * 1,000′ | 2,000′ | |
| 1/8 | .125 | 3.18 | .063 | 1.60 | .025 | 0.64 | * 1,000′ | 2,000′ | |
| 3/16 | .187 | 4.75 | .093 | 2.36 | .025 | 0.64 | * 1,000′ | 2,000′ | |
| 1/4 | .250 | 6.35 | .125 | 3.18 | .025 | 0.64 | * 1,000′ | 2,000′ | |
| 5/16 | .313 | 7.94 | .157 | 3.99 | .028 | 0.71 | * 500′ | 1,000′ | |
| 3/8 | .375 | 9.53 | .187 | 4.75 | .028 | 0.71 | * 500′ | 1,000′ | |
| 1/2 | .500 | 12.70 | .250 | 6.35 | .028 | 0.71 | * 250′ | 500′ | |
| 1/2 | .500 | 12.70 | .250 | 6.35 | .028 | 0.71 | 500′ | 1,000′ | |
| 5/8 | .625 | 15.88 | .313 | 7.94 | .033 | 0.84 | 250′ | 500′ | |
| 3/4 | .750 | 19.05 | .375 | 9.53 | .033 | 0.84 | 250′ | 500′ | |
| 1 | 1.000 | 25.40 | .500 | 12.70 | .038 | 0.97 | 250′ | 500′ | |
| 1 1/4 | 1.250 | 31.75 | .625 | 15.88 | .041 | 1.04 | 250′ | 500′ | |
| 1 1/2 | 1.500 | 38.10 | .750 | 19.05 | .043 | 1.09 | 100′ | 200′ | |
| 2 | 2.000 | 50.80 | 1.000 | 25.40 | .048 | 1.22 | 100′ | 200′ | |
| 2 1/2 | 2.500 | 63.50 | 1.250 | 31.75 | .058 | 1.47 | 100′ | 200′ | |
| 3 | 3.000 | 76.20 | 1.500 | 38.10 | .068 | 1.73 | 50′ | 100′ | |
| 4 | 4.000 | 101.60 | 2.000 | 50.80 | .073 | 1.85 | 50′ | 100′ | |
* Pressurized Spools
All information presented is believed to be reliable and is offered only as a guide to product selection. As each application is unique, Insultab can make no warranties as to the suitability of any products for a particular use. Specifications are subject to change.
